In small spaces where every inch is important—like crowded warehouses, narrow construction aisles, or small maintenance areas—theNarrow 6m Self-Propelled Electric Scissor Lift isn’t only made to work very well; it’s also built to change what a small lift can do.
It combines great ability to move easily (which lets it slide through gaps that bigger lifts can’t get past) and very good durability (which handles daily knocks, scrapes, and heavy use). You don’t have to choose between being easy to move and being strong here.
Its advanced all-electric drive system, too, works harder than a simple “zero-emission” label suggests. The Narrow 6m Self-Propelled Electric Scissor Lift enables fume-free operation, a must for indoor spaces where air quality matters, while packing enough power to tackle outdoor terrain: gravel lots, slightly sloped yards, even uneven concrete that would trip up less robust electric lifts. This isn’t just an eco-friendly choice—it’s a versatile one, eliminating the need to switch between indoor and outdoor machines for cross-site tasks.
And this compact, agile workhorse? It’s designed to do more than boost your productivity in the moment. By cutting out fuel costs (a big expense with gas-powered lifts) and reducing long-term maintenance needs (electric systems have fewer moving parts to service), it eases the strain on your budget over time. For any project where space is tight but performance and value can’t be compromised, the Narrow 6m Self-Propelled Electric Scissor Lift isn’t just a smart investment—it’s the lift that adapts to your needs, not the other way around.
Compact Design for Easy Access
Its body is optimized for tight spaces, allowing it to pass through standard doorways and reach the work area effortlessly.
Zero Inside Turn for Maximum Flexibility
It features a true zero inside turning radius, enabling pivoting within its own footprint for precise positioning in narrow aisles.
DC Power for Strong and Enduring Performance
The efficient DC drive motor delivers smooth, powerful performance and industry-leading runtime on a single charge.
Lightweight Construction Protects Floors
Its lightweight design significantly reduces ground pressure, making it ideal for sensitive floors like epoxy without causing damage.
Dual-Zone Controls Save Time and Effort
Operation from both the platform and ground level allows for precise spotting and movement, greatly enhancing workflow efficiency.
| Max. Working Height | 8m |
| Max. Platform Height | 6m |
| Overall Length | 1.85m |
| Overall Width | 0.79m |
| Overall Height(Guardrails unfolded) | 2.24m |
| Overall Height(Guardrails folded) | 1.68m |
| Platform Length(Stowed) | 1.68m |
| Platform Width | 0.74m |
| Max Horizontal Reach (Extension) | 0.9m |
| Load Capacity | 230kg |
| Load Capacity(Extension deck) | 110kg |
| Gradeability | 25% |
| Turning Radius (Inside) | 0.3m |
| Turning Radius (Outside) | 1.75m |
| Maximum Working Inclination Angle | X1.5°/Y3° |
| Tyre Size | φ305*114 |
| Battery | 4×6V/200Ah |
| Charger | 24v/30A |
| Total Weight | 1450Kg |
